| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1258 372 H91 | TACHOMETER INSTALLATION | 1 | F1 | |||
| ? | 1252 758 H91 | • TACHOMETER, ELECTRIC | 1 | ||||
| ? | 121 624 C1 | • SENSOR, TACHOMETER | 1 | ||||
| ? | 1267 855 H91 | • SOCKET ASSEMBLY, LAMP | 1 | ||||
| ? | 1284 828 H1 | • BULB | 1 | ||||
| ? | PANEL ASSEMBLY, INSTRUMENT (SEE PG 11-006) | -29 | 11AHG532.003 | ||||
| ? | HARNESS, INSTRUMENT PANEL (SEE PG 11-006) | -29 | 11AHG532.003 | ||||
| ? | HARNESS, ENGINE (SEE PG 08-002) | -29 | 08ADG382.001 | ||||
| ? | HOUSING, FLYWHEEL (SEE PG E8-006) | -29 | E8AF6B.002 | ||||
| ? | |||||||
| ? | F1 - NOT SERVICED. REFERENCE ONLY. | ||||||
| ? |
