| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 159 963 | CYLINDER ASSEMBLY, DRAWBAR SIDE SHIFT | 1 | ||||
| ? | 159 962 H45 | • CYLINDER WELDMENT - 3.50 IN. ID | 1 | ||||
| ? | 93 205 | • NUT, LOCK - TIGHTEN TO 400 FT/LBS WET | 1 | ||||
| ? | 140 149 | • PISTON | 1 | ||||
| ? | 162 895 | • KIT, CYLINDER HEAD REPLACEMENT | 1 | ||||
| ? | 82 232 | • • RING, SEAL RETAINING | 1 | ||||
| ? | 100 451 | • RING, CLAMP | 1 | ||||
| ? | 159 960 | • ROD WELDMENT | 1 | ||||
| ? | 1279 399 H91 | • KIT, CYLINDER SEAL | 1 | ||||
| ? | 403 844 R1 | • • WIPER, ROD | 1 | ||||
| ? | 65 985 | • • RING, BACK-UP | 1 | ||||
| ? | 354 836 R1 | • • O-RING | 1 | ||||
| ? | 58 614 | • • SEAL, ROD | 1 | ||||
| ? | 252 483 R1 | • • O-RING | 1 | ||||
| ? | 285 723 R1 | • • O-RING | 1 | ||||
| ? | 140 004 | • • RING, PISTON | 1 | ||||
| ? | 140 005 | • • RING, PISTON WEAR | 1 |
