| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1434 255 H91 | CYLINDER ASSEMBLY, LEANING WHEEL | 1 | ||||
| ? | 63 096 | • BUSHING | 2 | ||||
| ? | 1434 256 H91 | • CYLINDER WELDMENT | 1 | ||||
| ? | 93 205 | • NUT, LOCK | 1 | ||||
| ? | 1434 264 H1 | • PISTON | 1 | ||||
| ? | 1434 259 H91 | • ROD WELDMENT | 1 | ||||
| ? | 100 451 | • RING, CLAMP | 1 | ||||
| ? | 1434 263 H1 | • HEAD, CYLINDER | 1 | ||||
| ? | 1434 418 H91 | • KIT, CYLINDER SEAL | 1 | ||||
| ? | 403 844 R1 | • • WIPER, ROD | 1 | ||||
| ? | 65 985 | • • RING, BACK-UP | 1 | ||||
| ? | 354 836 R1 | • • O-RING | 1 | ||||
| ? | 58 614 | • • SEAL, ROD | 1 | ||||
| ? | 140 004 | • • RING, PISTON | 1 | ||||
| ? | 285 723 R1 | • • O-RING | 1 | ||||
| ? | 1434 257 H1 | • • RING, WEAR | 1 |
