| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1250 391 H91 | VALVE AND LEVER INSTALLATION - 10 VALVE | 1 | F3 | |||
| ? | 1260 529 H91 | VALVE AND LEVER INSTALLATION - 11 VALVE | 1 | F3 | |||
| ? | 1260 530 H91 | VALVE AND LEVER INSTALLATION - 12 VALVE | 1 | F3 | |||
| ? | 1250 350 H3 | • KNOB, RIPPER | A/R | ||||
| ? | 1250 351 H2 | • KNOB, DOZER/SNOW PLOW | A/R | ||||
| ? | 1250 352 H2 | • KNOB, AUXILIARY | A/R | ||||
| ? | 1232 274 H1 | • EPOXY, GENERAL PURPOSE | A/R | ||||
| ? | 1252 574 H91 | • LEVER ASSEMBLY | A/R | ||||
| ? | 120 437 H45 | • • BEARING | 2 | ||||
| ? | 1253 026 H2 | • WASHER, BEARING | A/R | ||||
| ? | 25 493 R1 | • BOLT | A/R | ||||
| ? | 120 214 | • WASHER, LOCK | A/R | ||||
| ? | 1244 338 H91 | • ROD ASSEMBLY, CONTROL | A/R | ||||
| ? | 514 358 C1 | • • END, ROD | 1 | ||||
| ? | 25 395 R1 | • • NUT, JAM | 2 | ||||
| ? | 1244 348 H1 | • • ROD, LINK | 1 | ||||
| ? | 1253 046 H1 | • • BOOT | 1 | ||||
| ? | 1244 350 H91 | • • ADAPTOR, SWIVEL | 1 | ||||
| ? | • LEVER, SCARIFIER (SEE PG 10-126) | -29 | 10AZG8II.001 | ||||
| ? | 1252 580 H91 | • LEVER ASSEMBLY | 1 | ||||
| ? | 120 437 H45 | • • BEARING | 2 | ||||
| ? | 1253 034 H1 | EXTENSION, UPPER SHAFT | A/R | ||||
| ? | 24 621 R1 | BOLT - 3/8-16 X 2 1/4 IN | A/R | ||||
| ? | 24 844 R1 | BOLT - 3/8-16 X 3 1/2 IN | A/R | ||||
| ? | |||||||
| ? | F1 - KITS ALSO INCLUDE VALVE SECTION, TIE ROD, STRAIGHT CONNECTORS | ||||||
| ? | AND O-RINGS: SEE PG 10-141, OR SEE PG 10-143, OR SEE PAGE 10-145. | ||||||
| ? | |||||||
| ? | F2 - FOR STANDARD CONTROL LEVERS SEE PG 05-007. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F3 - F1 AND F2 APPLY. | ||||||
| ? |
