| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1440 344 H91 | CONTROL MODULE ASSEMBLY | 1 | ||||
| ? | 1440 345 H1 | • MODULE, CONTROL | 1 | ||||
| ? | (NSS) | • • LEVER, FEEDBACK | 1 | ||||
| ? | (NSS) | • • SHIM | 1 | ||||
| ? | (NSS) | • • NEEDLE ROLLER | 1 | ||||
| ? | (NSS) | • • CONTROL PISTON WITH CYLINDER PIN | 1 | ||||
| ? | 1438 718 H1 | • • ARM, LEVER | 2 | ||||
| ? | (NSS) | • • PIN, ECCENTRIC | 1 | ||||
| ? | (NSS) | • • SHIM | 1 | ||||
| ? | (NSS) | • • SCREW, SOCKET-HEAD | 2 | ||||
| ? | (NSS) | • • SCREW, SOCKET-HEAD | 1 | ||||
| ? | (NSS) | • • PIN, DOUBLE BREAK | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | 1438 707 H1 | • COVER | 1 | ||||
| ? | 1440 346 H1 | • SPRING, DRAW | 1 | ||||
| ? | 1440 347 H1 | • GASKET | 1 | ||||
| ? | 1440 348 H1 | • ASSEMBLY PIECE | 2 | ||||
| ? | 1440 349 H1 | • SCREW, SOCKET-HEAD | 8 | ||||
| ? | 1440 350 H1 | • SCREW, SOCKET-HEAD | 4 | ||||
| ? | 1440 351 H1 | • O-RING | 1 | ||||
| ? | 1440 352 H1 | • O-RING | 3 | ||||
| ? | 1440 353 H1 | • SOLENOID, PROPORTIONAL | 2 | ||||
| ? | 1440 319 H1 | • O-RING | 2 | ||||
| ? | 1440 354 H1 | • O-RING | 1 | ||||
| ? | 1440 355 H1 | • O-RING | 2 | ||||
| ? | 1440 356 H1 | • SPRING, CUP | 2 | ||||
| ? | 1440 357 H1 | • PLUG, SOLENOID - BLACK | 1 | ||||
| ? | 134 313 | • PLUG, SOLENOID - GRAY | 1 | ||||
| ? | 1440 358 H1 | • PIN, CYLINDER | 1 |
