| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | NUT, HEX (SEE PG E7-004) | -29 | E7AO6B.002 | ||||
| ? | • GEAR (SEE PG E7-004) | -29 | E7AO6B.002 | ||||
| ? | (NSS) | • HUB | 1 | ||||
| ? | GASKET, PUMP DRIVE (SEE PG E7-004) | -29 | E7AO6B.002 | ||||
| ? | SPACER (SEE PG E7-004) | -29 | E7AO6B.002 | ||||
| ? | 1277 805 H1 | GASKET, PUMP DRIVE | 1 | ||||
| ? | 30 177 R1 | WASHER, FLAT | 2 | ||||
| ? | 30 043 R1 | BOLT | 2 | ||||
| ? | PUMP, STEERING AND BRAKE HYDRAULIC (SEE PG 10-104) | 10AVG8II.002 |
