| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | COOLER INSTALLATION, REAR AXLE OIL | 1 | |||||
| ? | 1430 868 H2 | • STRAINER | 1 | ||||
| ? | 876 108 C1 | • O-RING | 2 | ||||
| ? | 391 960 R91 | • ELBOW, REDUCING - 90 DEGREE | 2 | ||||
| ? | 876 106 C1 | • O-RING | 6 | ||||
| ? | 1436 329 H1 | • HOSE | 2 | ||||
| ? | • PUMP, DIFFERENTIAL HYDRAULIC (SEE PG 10-120) | -29 | 10AVG381.002 | ||||
| ? | 615 667 C1 | • ELBOW - 90 DEGREE | 1 | ||||
| ? | 882 779 C1 | • O-RING | 1 | ||||
| ? | 1430 824 H1 | • HOSE | 1 | F1 | |||
| ? | 48 494 | • GROMMET | 1 | ||||
| ? | 299 413 C1 | CLIP, CLOSED | 1 | ||||
| ? | 25 522 R1 | NUT | 1 | ||||
| ? | 25 896 R1 | WASHER | 1 | ||||
| ? | 9410 977 | • ELBOW - 90 DEGREE | 4 | ||||
| ? | 1436 317 H1 | • COOLER, REAR AXLE OIL | 1 | ||||
| ? | 140 483 H | • BOLT | 4 | ||||
| ? | 25 534 R1 | • WASHER, FLAT | 8 | ||||
| ? | 9413 979 | • NUT, LOCK | 4 | ||||
| ? | 1436 301 H91 | • BRACKET, OIL COOLER MOUNTING | 1 | ||||
| ? | 26 678 R1 | • BOLT | 2 | ||||
| ? | 27 326 R1 | • WASHER, FLAT | 2 | ||||
| ? | 1430 823 H1 | • HOSE | 1 | F1 | |||
| ? | 98 272 | • GROMMET | 1 | ||||
| ? | 9403 405 | • REDUCER | 1 | ||||
| ? | 9403 530 | • NUT, TUBE | 1 | ||||
| ? | 1437 284 H1 | • REDUCER - 90 DEGREE | 2 | ||||
| ? | 876 110 C1 | • O-RING | 2 | ||||
| ? | • FILTER, DIFFERENTIAL OIL (SEE PG 07-016) | -29 | 07BMG586.002 | ||||
| ? | 103 013 | • HOSE | 1 | ||||
| ? | 1436 509 H91 | • ELBOW - 90 DEGREE | 1 | ||||
| ? | 1436 507 H1 | • FITTING | 1 | ||||
| ? | AXLE, REAR (SEE PG 07-042) | -29 | 07HHG652.001 | ||||
| ? | AXLE, REAR (SEE PG 07-044) | -29 | 07HHG652.002 | ||||
| ? | |||||||
| ? | F1 - PROTECT HOSES TO COOLER WITH: | ||||||
| ? | 1431 377 H1 | • SLEEVE | 2 | ||||
| ? | 08034-20519 | • BAND | 3 |
