| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1267 347 H91 | LAMP ASSEMBLY, TURN SIGNAL | 2 | ||||
| ? | 1267 346 H91 | • LAMP, TURN SIGNAL | 1 | ||||
| ? | 1277 050 H1 | • • LENS, AMBER | 1 | ||||
| ? | 446 914 | • • BULB - 24 V | 1 | ||||
| ? | (NSS) | • • HOUSING | 1 | ||||
| ? | (NSS) | • • WASHER, GASKET | 1 | ||||
| ? | (NSS) | • • WASHER, LOCK | 1 | ||||
| ? | (NSS) | • • NUT, HEX | 1 | ||||
| ? | 1277 051 H1 | • • LENS, WHITE | 1 | ||||
| ? | 1277 052 H1 | • • INSERT | 1 | ||||
| ? | 1120 922 C1 | • TERMINAL | 1 | ||||
| ? | 739 070 C1 | • CONNECTOR | 1 |
