| Наименование | Страница | Код страницы |
|---|---|---|
| FIG. D5100-01A0 90 GALLON FUEL TANK | D-002 | D5100-01A0 |
| FIG. H5150-01A0 HYDRAULIC SYSTEM PUMP | H-074 | H5150-01A0 |
| FIG. H5220-01A0 NON-AWD HYDRAULIC OIL TANK | H-168 | H5220-01A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 9402 710 | CONNECTOR | 1 | ||||
| ? | 9410 334 | TEE | 1 | ||||
| ? | 9410 282 | ELBOW | 1 | ||||
| ? | 66 650 | HOSE | 1 | ||||
| ? | 9403 334 | PLUG, HYDRAULIC OIL DRAIN | 1 | ||||
| ? | 9403 333 | PLUG, FUEL TANK DRAIN | 1 | ||||
| ? | 935 522 C1 | STRAP, TIE | 3 | ||||
| ? | 162 918 | HOSE | 1 | ||||
| ? | 255 678 C1 | CONNECTOR | 1 | ||||
| ? | ( 66 650) | HOSE | 1 | ||||
| ? | (9410 978) | ELBOW - 90° | 1 | ||||
| ? | (364 885 R1) | O-RING | 1 |
