| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1434 846 H91 | DECALS, MODEL | 1 | ||||
| ? | 09690-B0200 | • KOMATSU | 1 | ||||
| ? | 09690-B0800 | • KOMATSU | 2 | ||||
| ? | 09690-B0315 | • KOMATSU | 2 | ||||
| ? | 1434 837 H1 | • GD650A | 2 | ||||
| ? | 1434 598 H91 | DECALS, STANDARD | 1 | ||||
| ? | 1283 701 H1 | • COOLANT CAUTION | 1 | ||||
| ? | 1433 788 H1 | • TIE DOWN | 8 | ||||
| ? | 1433 332 H2 | • HYDRAULIC OIL LEVEL | 1 | ||||
| ? | 1172 130 C1 | • READ MANUALS | 1 | ||||
| ? | 1246 037 H1 | • IMPORTANT - ALTERNATOR | 1 | ||||
| ? | 127 859 | • TAG, CAUTION | 1 | ||||
| ? | 163 344 | • RING, KEY | 1 | ||||
| ? | 1430 002 H1 | • TOWING | 1 | ||||
| ? | 1433 761 H1 | • HYDRAULIC OIL | 1 | ||||
| ? | 1433 747 H1 | • DIESEL FUEL | 1 | ||||
| ? | 1236 346 H2 | • WARNING | 1 | ||||
| ? | 1433 758 H1 | • OIL LEVEL | 2 | ||||
| ? | 1433 771 H1 | • LUBE CHART | 1 | ||||
| ? | 122 189 H45 | • TRANSMISSION FILL | 1 | ||||
| ? | 1285 791 H1 | • CAUTION | 1 | ||||
| ? | 1433 758 H1 | • OIL LEVEL | 1 | ||||
| ? | 1287 268 H1 | • CLEAN MOLDBOARD | 1 | ||||
| ? | 737 993 C3 | • CAUTION - ROLLOVER | 1 | ||||
| ? | (NSS) | • PLATE, SERIAL NO. | 1 | ||||
| ? | 127 738 | • SCREW, DRIVE | 4 | ||||
| ? | 1263 073 H2 | • DANGER | 2 | ||||
| ? | 1430 877 H1 | • WARNING - ACCUMULATORS | 1 | ||||
| ? | 1270 967 H1 | • IMPORTANT - TRANSMISSION CHECK | 1 | ||||
| ? | 1260 702 H1 | • DANGER | 2 | ||||
| ? | 1279 588 H1 | • TREAD, STEP - R.H. TANDEM CASE | 4 | ||||
| ? | 895 269 C1 | • ADHESIVE | A/R |
