Номер на схеме	Каталожный номер	Название	Количество
?	1430 897 H91	GEAR CASE ASSEMBLY, CIRCLE REVERSE	1
?	60 556	• RETAINER, BEARING	1
?	24 841 R1	• BOLT	6
?	25 534 R1	• WASHER, FLAT	6
?	28 762 A	• SHIM 0.003	3
?	55 073	• SHIM 0.005	3
?	28 762 B	• SHIM 0.020	2
?	58 420	• NUT, LOCK	1
?	85 080	• PLUG, PIPE - OIL FILL	1
?	74 947	• BREATHER	1
?	1431 165 H93	• COVER, CIRCLE REVERSE CASE	1
?	80 295 R1	• BOLT	6
?	25 546 R1	• WASHER, FLAT	6
?	26 533 R1	• O-RING	1
?	59 490 A	• WASHER	1
?	26 233	• BEARING	1
?	28 795	• BEARING	1
?	60 235 A	• GEAR, CIRCLE REVERSE	1
?	42 212	• CONE, BEARING	1
?	42 215	• BEARING	1
?	1269 175 H1	• SEAL, OIL	1
?		• CLUTCH ASSEMBLY (FIG. T5520-01A3)	1
?	39 214 B	• CASE, CIRCLE REVERSE	1
?	444 693	• PLUG, PIPE - OIL LEVEL AND DRAIN	2
?	28 796	• BEARING	2
?	28 797	• BEARING	2
?	60 230	• WORM, CIRCLE REVERSE	1
?	28 781 A	• SHIM 0.003	2
?	28 781 B	• SHIM 0.005	4
?	28 781 C	• SHIM 0.020	5
?	28 765	• CAP, END	1
?	24 841 R1	• BOLT	6
?	25 534 R1	• WASHER, FLAT	6
