| Наименование | Страница | Код страницы |
|---|---|---|
| FIG. K5170-01A2A SEAT BOX - S/N 203918 AND UP | K-016 | K5170-01A2A |
| FIG. K5380-01A0 REAR VIEW MIRROR - INSIDE MOUNTING | K-090 | K5380-01A0 |
| FIG. K5410-01A0 FLOOR PLATE | K-106 | K5410-01A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 099 H92 | CAB ASSEMBLY | 1 | SN: 202642 AND UP- |
|||
| ? | 1433 915 H91 | • CAB WELDMENT | 1 | SN: 202642 AND UP- |
|||
| ? | 1259 658 H91 | • COVER - L.H. | 1 | SN: 202642 AND UP- |
|||
| ? | 180 020 | • BOLT | 8 | SN: 202642 AND UP- |
|||
| ? | 120 392 | • WASHER, FLAT | 8 | SN: 202642 AND UP- |
|||
| ? | 1259 657 H91 | • COVER - R.H. | 1 | SN: 202642 AND UP- |
|||
| ? | 120 302 | • GROMMET, TOP LIGHTS | 2 | SN: 202642 AND UP- |
|||
| ? | 1434 775 H91 | • COVER, FRONT WIPER MOTOR | 1 | SN: 202642 AND UP- |
|||
| ? | 24 539 R1 | • PLUG, BUTTON - 1 IN. | 1 | SN: 202642 AND UP- |
|||
| ? | 180 016 | • BOLT | 4 | SN: 202642 AND UP- |
|||
| ? | 120 392 | • WASHER, FLAT | 4 | SN: 202642 AND UP- |
|||
| ? | 1252 463 H1 | • ANGLE, UPPER SIDE - AIR RECIRCULATION | 2 | SN: 202642 AND UP- |
|||
| ? | • TRIM, DOOR EDGE - 167 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, BOTTOM SIDE WINDOW EDGE-95.3 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, TOP SIDE WINDOW EDGE - 90 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, EDGE - 2.1 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, EDGE - 4 IN. | 4 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, EDGE - 3 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, WINDOW EDGE - 158 IN. | 1 | SN: 202642 AND UP- |
F1 | |||
| ? | • TRIM, BOTTOM FRONT WINDOW EDGE-109 IN. | 2 | SN: 202642 AND UP- |
F1 | |||
| ? | 1434 778 H1 | • COVER | 1 | SN: 202642 AND UP- |
|||
| ? | 180 016 | • BOLT | 3 | SN: 202642 AND UP- |
|||
| ? | 120 392 | • WASHER, FLAT | 3 | SN: 202642 AND UP- |
|||
| ? | 149 149 | • SEAL - 11.91 IN. | 1 | SN: 202642 AND UP- |
|||
| ? | 104 696 | • ADHESIVE, RUBBER | A/R | SN: 202642 AND UP- |
|||
| ? | 1433 790 H1 | • HOOK, COAT | 1 | SN: 202642 AND UP- |
|||
| ? | 23 979 R1 | • SCREW, MACHINE | 2 | SN: 202642 AND UP- |
|||
| ? | 1433 538 H91 | • WIRING HARNESS, CAB | 1 | SN: 202642 AND UP- |
|||
| ? | 299 415 C1 | • CLAMP, CABLE | 2 | SN: 202642 AND UP- |
|||
| ? | 120 375 | • NUT, HEX | 2 | SN: 202642 AND UP- |
|||
| ? | 180 124 | BOLT | 8 | SN: 202642 AND UP- |
|||
| ? | 25 553 R1 | WASHER, FLAT | 8 | SN: 202642 AND UP- |
|||
| ? | |||||||
| ? | F1 CUT TO LENGTH FROM P/N 1262 660 H1 | ||||||
| ? |
