| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 24 895 R1 | BOLT | 2 | ||||
| ? | 25 538 R1 | WASHER, FLAT | 2 | ||||
| ? | 112 434 | WASHER, SPECIAL - ROPS | 2 | ||||
| ? | 113 985 | MOUNT, RUBBER | 4 | ||||
| ? | 9413 983 | NUT, LOCK | 2 | ||||
| ? | OR | ||||||
| ? | 26 720 R1 | BOLT | 4 | ||||
| ? | 25 550 R1 | WASHER, FLAT | 4 | ||||
| ? | 1244 349 H1 | WASHER, SPECIAL - ROPS | 4 | ||||
| ? | 213 042 H1 | MOUNT, RUBBER | 4 | ||||
| ? | 9414 002 | NUT, LOCK | 4 | ||||
| ? | OR |
