| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1436 523 H92 | ACCUMULATOR (4.75 X 16.19 IN.) | 1 | SN: 211061-211069- |
|||
| ? | 1439 480 H1 | • BODY | 1 | SN: 211061-211069- |
|||
| ? | 1439 484 H91 | • KIT, SEAL | 1 | SN: 211061-211069- |
|||
| ? | 1439 490 H1 | • • SEAL, BODY END | 2 | SN: 211061-211069- |
|||
| ? | 1439 491 H1 | • • WASHER, BACK-UP | 2 | SN: 211061-211069- |
|||
| ? | 1439 485 H1 | • • RING, PTFE | 2 | SN: 211061-211069- |
|||
| ? | 1439 489 H1 | • • WASHER, BACK-UP | 2 | SN: 211061-211069- |
|||
| ? | 1439 488 H1 | • • V-RING | 1 | SN: 211061-211069- |
|||
| ? | 3046 105 R1 | • • O-RING, GAS VALVE | 1 | SN: 211061-211069- |
|||
| ? | 1439 481 H1 | • CAP, HYDRAULIC | 1 | SN: 211061-211069- |
|||
| ? | 1439 483 H1 | • PISTON | 1 | SN: 211061-211069- |
|||
| ? | 1439 482 H1 | • CAP, GAS | 1 | SN: 211061-211069- |
|||
| ? | 1286 935 H91 | • VALVE, GAS | 1 | SN: 211061-211069- |
F1 | ||
| ? | (NSS) | • • CAP, GAS VALVE | 1 | SN: 211061-211069- |
|||
| ? | 1439 486 H1 | • PROTECTOR, GAS VALVE | 1 | SN: 211061-211069- |
|||
| ? | 1439 487 H1 | • SCREW | 2 | SN: 211061-211069- |
|||
| ? | |||||||
| ? | F1 INCLUDES P/N 3046 105 R1 O-RING, ITEM 7 | ||||||
| ? |
