| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | 708-2L-35530 | • PLUG | 2 | SN: A85001-- |
|||
| ? | 07002-61023 | • O-RING | 2 | SN: A85001-- |
|||
| ? | 702-21-55600 | • VALVE, PILOT PRESSURE SENSING | 1 | SN: A85001-- |
|||
| ? | 01252-60635 | • BOLT | 2 | SN: A85001-- |
|||
| ? | 20Y-62-22790 | • BAND, RED | 1 | SN: A85001-- |
|||
| ? | 702-21-55701 | • VALVE, PILOT PRESSURE SENSING | 1 | SN: A85001-- |
|||
| ? | 702-16-55260 | • BOLT | 2 | SN: A85001-- |
|||
| ? | 20Y-62-22830 | • BAND, WHITE | 1 | SN: A85001-- |
|||
| ? | 702-21-55400 | • VALVE ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | 702-21-55920 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 702-21-55930 | • • PISTON | 1 | SN: A85001-- |
|||
| ? | 702-21-55940 | • • SPRING | 1 | SN: A85001-- |
|||
| ? | 702-21-55951 | • • BLOCK | 1 | SN: A85001-- |
|||
| ? | 07002-12034 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07000-11008 | • O-RING | 2 | SN: A85001-- |
|||
| ? | 722-12-18240 | • O-RING | 1 | SN: A85001-- |
|||
| ? | 01252-60530 | • BOLT | 1 | SN: A85001-- |
|||
| ? | 708-2G-03450 | • PLUG SUB ASSEMBLY | 2 | SN: A85001-- |
|||
| ? | 708-2G-15670 | • • PLUG | 1 | SN: A85001-- |
F1 | ||
| ? | (NSS) | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07000-B1008 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07001-01008 | • • RING | 2 | SN: A85001-- |
|||
| ? | 07000-B1007 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07001-01007 | • • RING, BACK-UP | 1 | SN: A85001-- |
|||
| ? | 07002-61423 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 01643-51232 | • WASHER | 3 | SN: A85001-- |
|||
| ? | 01010-81220 | • BOLT | 3 | SN: A85001-- |
|||
| ? | 08193-21012 | • CLIP | 2 | SN: A85001-- |
|||
| ? | 29 | ||||||
| ? | F1 - THIS PART WILL NOT BE SUPPLIED AS AN INDIVIDUAL PART. IT IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS. | 30 |
