| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | • PUMP SUB ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | 708-2G-03430 | • • COVER ASSEMBLY | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-14310 | • • • SCREW | 1 | SN: A85001-- |
F1 | ||
| ? | 07000-B3038 | • • • O-RING | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-15230 | • • • RING, BACK-UP | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2L-35540 | • • • NUT | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-14170 | • • • COVER | 1 | SN: A85001-- |
F1 | ||
| ? | 07000-B2050 | • • • O-RING | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-15310 | • • • RING | 1 | SN: A85001-- |
F1 | ||
| ? | 01252-61645 | • • BOLT | 4 | SN: A85001-- |
F1 | ||
| ? | 11 | ||||||
| ? | F1 - THIS PART WILL NOT BE SUPPLIED AS AN INDIVIDUAL PART. IT IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS. | 12 |
