| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | • PUMP SUB ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | 708-2G-12121 | • • SHAFT, REAR | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-12251 | • • BEARING | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-05010 | • • WASHER KIT | 1 | SN: A85001-- |
F1 | ||
| ? | 708-1F-12270 | • • RING, SNAP | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-04151 | • • BLOCK ASSEMBLY, REAR | 1 | SN: A85001-- |
F1 | ||
| ? | (NSS) | • • • BLOCK, CYLINDER | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • PLATE, VALVE | 1 | SN: A85001-- |
|||
| ? | 708-18-13230 | • • PIN | 1 | SN: A85001-- |
F1 | ||
| ? | 04065-05520 | • • RING, SNAP | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13131 | • • SEAT | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13152 | • • SPRING | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13141 | • • SEAT | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13510 | • • GUIDE, RETAINER | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2H-23360 | • • PIN | 3 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13341 | • • RETAINER, SHOE | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2G-13311 | • • PISTON SUB ASSEMBLY | 9 | SN: A85001-- |
F1 | ||
| ? | 708-2G-04161 | • • CRADLE ASSEMBLY | 1 | SN: A85001-- |
F1 | ||
| ? | (NSS) | • • • CRADLE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • CAM, ROCKER | 1 | SN: A85001-- |
|||
| ? | 04020-01434 | • • PIN | 1 | SN: A85001-- |
F1 | ||
| ? | 07000-B1009 | • • O-RING | 1 | SN: A85001-- |
F1 | ||
| ? | 01252-61230 | • • BOLT | 6 | SN: A85001-- |
F1 | ||
| ? | 708-2G-12130 | • • COUPLING | 1 | SN: A85001-- |
F1 | ||
| ? | 708-2F-12420 | • • RING | 1 | SN: A85001-- |
F1 | ||
| ? | 26 | ||||||
| ? | F1 - THIS PART WILL NOT BE SUPPLIED AS AN INDIVIDUAL PART. IT IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS. | 27 |
