| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | • PUMP SUB ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | 708-2G-04124 | • • CASE ASSEMBLY, REAR | 1 | SN: A85001-- |
F1 | ||
| ? | (NSS) | • • • CASE, REAR | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • PLUG | 33 | SN: A85001-- |
|||
| ? | 07044-12412 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-62434 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 20B-27-11210 | • • BLEEDER | 1 | SN: A85001-- |
|||
| ? | 708-2L-25650 | • • ORIFICE | 1 | SN: A85001-- |
|||
| ? | 04530-01222 | • • BOLT, EYE | 1 | SN: A85001-- |
|||
| ? | 708-2G-19110 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-63334 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 708-8E-16150 | • • PLUG | 4 | SN: A85001-- |
|||
| ? | 07002-61023 | • • O-RING | 4 | SN: A85001-- |
|||
| ? | 07040-12414 | • • PLUG | 2 | SN: A85001-- |
|||
| ? | 07002-62434 | • • O-RING | 2 | SN: A85001-- |
|||
| ? | 16 | ||||||
| ? | F1 - THIS PART WILL NOT BE SUPPLIED AS AN INDIVIDUAL PART. IT IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS. | 17 |
