| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | • PUMP SUB ASSEMBLY (SEE FIG. H0210-01A0 ) | SN: A85001-- |
H0210-01A0 | ||||
| ? | 708-2G-04132 | • • CAP ASSEMBLY, END | 1 | SN: A85001-- |
F1 | ||
| ? | (NSS) | • • • CAP, END | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • PLUG | 18 | SN: A85001-- |
|||
| ? | 708-2G-12151 | • • BEARING | 2 | SN: A85001-- |
F1 | ||
| ? | 07000-A5185 | • • O-RING | 2 | SN: A85001-- |
F1 | ||
| ? | 04020-01434 | • • PIN | 2 | SN: A85001-- |
F1 | ||
| ? | 07000-B2012 | • • O-RING | 7 | SN: A85001-- |
F1 | ||
| ? | 01010-61655 | • • BOLT | 12 | SN: A85001-- |
F1 | ||
| ? | 01643-51645 | • • WASHER | 12 | SN: A85001-- |
F1 | ||
| ? | 07000-B2014 | • • O-RING | 4 | SN: A85001-- |
F1 | ||
| ? | 708-2L-25480 | • • FILTER | 4 | SN: A85001-- |
F1 | ||
| ? | 708-8E-16150 | • • PLUG | 3 | SN: A85001-- |
|||
| ? | 07002-61023 | • • O-RING | 3 | SN: A85001-- |
|||
| ? | 15 | ||||||
| ? | F1 - THIS PART WILL NOT BE SUPPLIED AS AN INDIVIDUAL PART. IT IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS. | 16 |
