| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE ASSEMBLY, MAIN CONTROL (SEE FIG. H0120-00A0 ) | SN: A85001-- |
H0120-00A0 | ||||
| ? | (NSS) | • BODY SUB ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | 709-74-91510 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07000-13024 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07000-11009 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07001-01009 | • • RING, BACK-UP | 1 | SN: A85001-- |
|||
| ? | 723-40-91200 | • VALVE ASSEMBLY, PRESSURE COMPENSATION | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SLEEVE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SLEEVE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • POPPET | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • PISTON | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • PLUG | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • POPPET | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPACER | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SEAL | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SEAL | 1 | SN: A85001-- |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • NUT | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • NUT | 1 | SN: A85001-- |
|||
| ? | 723-40-66300 | • VALVE ASSEMBLY, LS SHUTTLE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • CASE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SEAT | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SEAT | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • BALL | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • PLUG | 2 | SN: A85001-- |
|||
| ? | 01252-60845 | • • BOLT | 4 | SN: A85001-- |
|||
| ? | 01643-50823 | • • WASHER | 4 | SN: A85001-- |
