| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE ASSEMBLY, MAIN CONTROL (SEE FIG. H0120-00A0 ) | SN: A85001-- |
H0120-00A0 | ||||
| ? | (NSS) | • BODY SUB ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | 723-46-41210 | • • VALVE | 2 | SN: A85001-- |
|||
| ? | 723-46-40601 | • • VALVE ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SLEEVE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • PISTON SUB ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SPRING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SEAL | 2 | SN: A85001-- |
|||
| ? | 700-93-11320 | • • • O-RING | 1 | SN: A85001-- |
|||
| ? | 723-46-41950 | • • • RING | 2 | SN: A85001-- |
|||
| ? | 07002-13634 | • • • O-RING | 1 | SN: A85001-- |
|||
| ? | 723-46-43100 | • • VALVE ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SLEEVE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • PISTON SUB ASSEMBLY | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SPRING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • • SEAL | 2 | SN: A85001-- |
|||
| ? | 700-93-11320 | • • • O-RING | 1 | SN: A85001-- |
|||
| ? | 723-46-41950 | • • • RING | 2 | SN: A85001-- |
|||
| ? | 07002-13634 | • • • O-RING | 1 | SN: A85001-- |
