| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE ASSEMBLY, MAIN CONTROL (SEE FIG. H0120-00A0 ) | SN: A85001-- |
H0120-00A0 | ||||
| ? | • VALVE ASSEMBLY (SEE FIG. H0120-13A0 ) | SN: A85001-- |
H0120-13A0 | ||||
| ? | • VALVE ASSEMBLY (SEE FIG. H0120-13A0 ) | SN: A85001-- |
H0120-13A0 | ||||
| ? | 723-40-71430 | • • VALVE | 1 | SN: A85001-- |
|||
| ? | 702-21-55460 | • • SPRING | 1 | SN: A85001-- |
|||
| ? | 702-21-55420 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 702-21-55520 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 702-21-55440 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 702-21-53120 | • • FILTER | 1 | SN: A85001-- |
|||
| ? | 07000-12011 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • BLOCK | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPOOL | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A85001-- |
|||
| ? | 702-21-55620 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 702-21-55710 | • • SEAT | 1 | SN: A85001-- |
|||
| ? | 702-21-55720 | • • SPRING | 1 | SN: A85001-- |
|||
| ? | 04260-00793 | • • BALL | 1 | SN: A85001-- |
|||
| ? | 07000-11009 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • PLUG | 2 | SN: A85001-- |
|||
| ? | 708-8H-11530 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 01252-61040 | • • BOLT | 3 | SN: A85001-- |
|||
| ? | 01643-51032 | • • WASHER | 3 | SN: A85001-- |
|||
| ? | 708-8H-11530 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 702-21-55620 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 708-8E-16160 | • • PLUG | 1 | SN: A85001-- |
|||
| ? | 07002-11023 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | 07000-12011 | • • O-RING | 1 | SN: A85001-- |
|||
| ? | (NSS) | • • PLUG | 17 | SN: A85001-- |
|||
| ? | 01010-61460 | • BOLT | 1 | SN: A85001-- |
|||
| ? | 01010-61470 | • BOLT | 3 | SN: A85001-- |
|||
| ? | 01643-31445 | • WASHER | 4 | SN: A85001-- |
