| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-30-00150 | ROLLER ASSEMBLY, TRACK | 1 | ||||
| ? | 207-30-56112 | • ROLLER TRACK | 1 | ||||
| ? | 207-30-56140 | • BUSHING | 2 | ||||
| ? | 207-30-56131 | • SHAFT | 1 | ||||
| ? | 427-15-15910 | • O-RING | 2 | ||||
| ? | 20Y-30-00101 | • SEAL ASSEMBLY, FLOATING | 2 | ||||
| ? | 20Y-30-00111 | • • RING ASSEMBLY, SEAL | 1 | ||||
| ? | (NSS) | • • • SEAL | 2 | ||||
| ? | 20Y-30-00121 | • • O-RING ASSEMBLY | 1 | ||||
| ? | (NSS) | • • • O-RING | 2 | ||||
| ? | 207-30-56152 | • COLLAR | 1 | ||||
| ? | 299-10-14160 | • PLUG | 1 | ||||
| ? | 207-30-56162 | • COLLAR | 1 | ||||
| ? | 207-30-56170 | • PIN | 2 | ||||
| ? | 207-30-56190 | • BOLT | 4 | ||||
| ? | 01643-32060 | • WASHER | 4 |
