| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-01-58210 | BRACKET | 1 | ||||
| ? | 01010-51240 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 207-01-58251 | BRACKET | 1 | ||||
| ? | 01010-51645 | BOLT | 6 | ||||
| ? | 01643-31645 | WASHER | 6 | ||||
| ? | 207-01-58261 | BRACKET | 1 | ||||
| ? | 01010-51645 | BOLT | 6 | ||||
| ? | 01643-31645 | WASHER | 6 | ||||
| ? | 207-01-58220 | BRACKET | 1 | ||||
| ? | 01010-51275 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 195-43-41530 | SPACER | 4 | ||||
| ? | 23S-01-11140 | CUSHION | 4 | ||||
| ? | 207-01-55320 | STOPPER | 2 | ||||
| ? | 207-01-55310 | STOPPER | 2 | ||||
| ? | 207-01-55210 | COLLAR | 2 | ||||
| ? | 207-01-55181 | BOLT | 2 | ||||
| ? | 01643-31845 | WASHER | 2 | ||||
| ? | 208-01-55220 | CUSHION | 4 | ||||
| ? | 207-01-55380 | STOPPER | 2 | ||||
| ? | 208-01-55350 | STOPPER | 2 | ||||
| ? | 207-01-55370 | COLLAR | 2 | ||||
| ? | 208-01-11181 | BOLT | 2 | ||||
| ? | 01643-32460 | WASHER | 2 | ||||
| ? | 207-01-55390 | PLATE | 2 | ||||
| ? | 207-46-31180 | PLATE | 2 | ||||
| ? | 207-01-58310 | COVER | 1 | ||||
| ? | FRAME, REVOLVING (SEE PG 04-018) | -29 | 04-018 | ||||
| ? | 207-01-A1111 | ENGINE ASSEMBLY | 1 | F1 | |||
| ? | |||||||
| ? | F1 - FOR SERVICE PARTS REFER TO SECTION E. | ||||||
| ? |
