| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TRAVEL MOTOR ASSEMBLY (SEE PG 06-102) | -29 | 06-102 | ||||
| ? | 702-76-01401 | • VALVE ASSEMBLY, TRAVEL MOTOR CROSS-OVER RELIEF | 2 | ||||
| ? | (NSS) | • SLEEVE | 1 | ||||
| ? | (NSS) | • SEAT, VALVE | 1 | ||||
| ? | (NSS) | • O-RING | 1 | ||||
| ? | (NSS) | • RING | 1 | ||||
| ? | (NSS) | • SLEEVE | 1 | ||||
| ? | (NSS) | • POPPET | 1 | ||||
| ? | (NSS) | • SPRING | 1 | ||||
| ? | (NSS) | • SEAT | 1 | ||||
| ? | (NSS) | • O-RING | 1 | ||||
| ? | (NSS) | • RING | 1 | ||||
| ? | (NSS) | • CAP | 1 | ||||
| ? | (NSS) | • O-RING | 1 | ||||
| ? | (NSS) | • SCREW | 1 | ||||
| ? | (NSS) | • NUT | 1 | ||||
| ? | (NSS) | • SPRING | 1 | ||||
| ? | (NSS) | • VALVE | 1 | ||||
| ? | (NSS) | • SEAT, VALVE | 1 | ||||
| ? | 07000-22020 | • O-RING | 1 | ||||
| ? | 07001-02020 | • RING | 2 | ||||
| ? | 07002-13034 | • O-RING | 1 | ||||
| ? | • • COVER ASSEMBLY, END (SEE PG 06-106) | -29 | 06-106 |
