| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 234-46-31110 | FRAME | 1 | SN: 10002- |
|||
| ? | 234-46-31280 | BUSHING | 2 | SN: 10002- |
|||
| ? | 07000-15100 | O-RING | 2 | SN: 10002- |
|||
| ? | 234-46-31290 | PIN | 4 | SN: 10002- |
|||
| ? | 04082-00206 | LOCK | 4 | SN: 10002- |
|||
| ? | 01602-21236 | WASHER | 8 | SN: 10002- |
|||
| ? | □01010-51225 | BOLT | 8 | SN: 10002- |
|||
| ? | 232-45-13130 | PIN | 1 | SN: 10002- |
|||
| ? | 07020-00900 | FITTING | 4 | SN: 10002- |
|||
| ? | 234-46-31260 | COVER | 1 | SN: 10002- |
|||
| ? | ♦01010-51020 | BOLT | 4 | SN: 10002- |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 10002- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 10002- |
|||
| ? | 234-46-33100 | FRAME | 1 | SN: 10002- |
|||
| ? | 234-46-32580 | CAP | 2 | SN: 10002- |
|||
| ? | □01011-82050 | BOLT | 8 | SN: 10002- |
|||
| ? | 01643-32060 | WASHER | 8 | SN: 10002- |
|||
| ? | 232-46-54190 | PIN | 2 | SN: 10002- |
|||
| ? | 232-46-54560 | ELBOW | 1 | SN: 10002- |
|||
| ? | □232-46-54570 | TUBE | 1 | SN: 10002- |
|||
| ? | 07020-00000 | FITTING | 1 | SN: 10002- |
|||
| ? | 236-46-13380 | BUSHING | 2 | SN: 10002- |
|||
| ? | 236-46-13390 | BUSHING | 2 | SN: 10002- |
|||
| ? | 236-46-13410 | NUT | 2 | SN: 10002- |
|||
| ? | 01010-51230 | BOLT | 1 | SN: 10002- |
|||
| ? | 01602-21236 | WASHER | 1 | SN: 10002- |
|||
| ? | 236-46-13420 | PLATE | 2 | SN: 10002- |
|||
| ? | □01010-51630 | BOLT | 4 | SN: 10002- |
|||
| ? | 01602-21648 | WASHER | 4 | SN: 10002- |
|||
| ? | 01643-31645 | WASHER | 4 | SN: 10002- |
|||
| ? | 236-46-13610 | O-RING | 4 | SN: 10002- |
|||
| ? | 236-46-13620 | BOLT | 4 | SN: 10002- |
|||
| ? | □01598-10608 | NUT | 4 | SN: 10002- |
|||
| ? | 01640-20610 | WASHER | 8 | SN: 10002- |
|||
| ? | 07020-00000 | FITTING | 1 | SN: 10002- |
|||
| ? | 232-46-51350 | PLATE | 1 | SN: 10002- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 10002- |
|||
| ? | 01602-21236 | WASHER | 4 | SN: 10002- |
|||
| ? | □01010-51225 | BOLT | 4 | SN: 10002- |
|||
| ? | 234-46-53210 | BUSHING | 2 | SN: 10002- |
