| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CYLINDER, L.H. (SEE FIG. H3410-06B0) | SN: A10001-- |
H3410-06B0 | ||||
| ? | CYLINDER, R.H. (SEE FIG. H3410-06B0) | SN: A10001-- |
H3410-06B0 | ||||
| ? | 56B-61-11952 | TUBE | 1 | SN: A10001-- |
|||
| ? | 56B-61-11571 | TUBE | 1 | SN: A10001-- |
|||
| ? | 56C-61-11960 | CLAMP | 2 | SN: A10001-- |
|||
| ? | 56C-61-11970 | CLAMP | 1 | SN: A10001-- |
|||
| ? | 56C-61-11980 | CLAMP | 1 | SN: A10001-- |
|||
| ? | 01010-81030 | BOLT | 4 | SN: A10001-- |
|||
| ? | 01643-31032 | WASHER | 8 | SN: A10001-- |
|||
| ? | 01580-11008 | NUT | 4 | SN: A10001-- |
|||
| ? | 07283-32738 | CLIP | 2 | SN: A10001-- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: A10001-- |
|||
| ? | 01597-01009 | NUT | 4 | SN: A10001-- |
|||
| ? | 21W-62-42550 | ELBOW | 4 | SN: A10001-- |
|||
| ? | 07002-22434 | O-RING | 4 | SN: A10001-- |
|||
| ? | 02896-21018 | O-RING | 4 | SN: A10001-- |
|||
| ? | 56B-60-11810 | PIN | 4 | SN: A10001-- |
|||
| ? | 01010-81625 | BOLT | 4 | SN: A10001-- |
|||
| ? | 421-70-11280 | WASHER | 4 | SN: A10001-- |
|||
| ? | 417-70-11340 | SHIM, 1.5MM | 16 | SN: A10001-- |
|||
| ? | 417-70-11370 | SHIM, 0.5MM | 16 | SN: A10001-- |
|||
| ? | 07020-00675 | FITTING, GREASE | 2 | SN: A10001-- |
|||
| ? | 423-70-11160 | NIPPLE | 4 | SN: A10001-- |
|||
| ? | 07020-00000 | FITTING, GREASE | 2 | SN: A10001-- |
