| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-815-3600 | CONTROL UNIT ASS'Y,A.P.S. | 1 | SN: 18607- |
|||
| ? | 600-815-4220 | • CONTROL ASS'Y,A.P.S. | 1 | SN: 18607- |
|||
| ? | 600-815-3440 | • RESISTOR | 1 | SN: 18607- |
|||
| ? | 600-815-2520 | • SWITCH | 1 | SN: 18607- |
|||
| ? | 600-815-3611 | • TIMER | 1 | SN: 18607- |
|||
| ? | 6128-81-4510 | • BRACKET | 1 | SN: 18607- |
|||
| ? | 600-815-3470 | • HARNESS,WIRE | 1 | SN: 18607- |
|||
| ? | 600-815-3450 | • HARNESS,WIRE | 1 | SN: 18607- |
|||
| ? | 01220-40612 | • SCREW | 8 | SN: 18607- |
|||
| ? | 01220-40408 | • SCREW | 7 | SN: 18607- |
|||
| ? | 01220-40512 | • SCREW | 2 | SN: 18607- |
|||
| ? | 01601-00410 | • WASHER,SPRING | 7 | SN: 18607- |
|||
| ? | 01601-00513 | • WASHER,SPRING | 2 | SN: 18607- |
|||
| ? | 01602-00619 | • WASHER,SPRING | 8 | SN: 18607- |
|||
| ? | 01641-20405 | • WASHER | 7 | SN: 18607- |
|||
| ? | 01641-20608 | • WASHER | 8 | SN: 18607- |
|||
| ? | 01641-20508 | • WASHER | 2 | SN: 18607- |
|||
| ? | 08147-21200 | LAMP | 1 | SN: 18607- |
|||
| ? | 08061-30070 | SWITCH | 1 | SN: 18607- |
|||
| ? | 08027-02930 | CONNECTOR | 1 | SN: 18607- |
|||
| ? | 08027-01610 | CONNECTOR | 1 | SN: 18607- |
|||
| ? | 08027-02420 | CONNECTOR | 1 | SN: 18607- |
|||
| ? | 175-07-33520 | RELAY | 1 | SN: 18607- |
