| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-63-6470 | CONNECTOR | 1 | SN: 18607- |
|||
| ? | 01010-81025 | BOLT | 5 | SN: 18607- |
|||
| ? | 01602-01030 | WASHER,SPRING | 5 | SN: 18607- |
|||
| ? | 6162-63-6390 | TUBE | 1 | SN: 18607- |
|||
| ? | 6166-61-6680 | O-RING | 2 | SN: 18885- |
|||
| ? | ♦07000-G3038 | O-RING | 2 | SN: 18607-18884 |
|||
| ? | 6162-63-6480 | CONNECTOR | 2 | SN: 18607- |
|||
| ? | 6162-63-6841 | GASKET | 4 | SN: 18607- |
|||
| ? | 01010-81035 | BOLT | 8 | SN: 18607- |
|||
| ? | 01602-01030 | WASHER,SPRING | 8 | SN: 18607- |
|||
| ? | 07043-00312 | PLUG | 2 | SN: 18607- |
|||
| ? | 02720-20204 | PLUG | 2 | SN: 18607- |
|||
| ? | 6162-63-6210 | TUBE | 1 | SN: 18607- |
|||
| ? | 6166-61-6680 | O-RING | 2 | SN: 18885- |
|||
| ? | ♦07000-G3038 | O-RING | 2 | SN: 18607-18884 |
|||
| ? | 6128-11-6812 | GASKET | 1 | SN: 18607- |
|||
| ? | 01010-81065 | BOLT | 2 | SN: 18607- |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 18607- |
|||
| ? | 6162-63-6490 | CONNECTOR | 1 | SN: 18607- |
|||
| ? | 6162-63-6440 | TUBE | 1 | SN: 18607- |
|||
| ? | 6166-61-6680 | O-RING | 2 | SN: 18885- |
|||
| ? | ♦07000-G3038 | O-RING | 2 | SN: 18607-18884 |
|||
| ? | 01010-81030 | BOLT | 1 | SN: 18607- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 18607- |
