| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-73-3503 | HOUSING ASS'Y | 1 | SN: 18607- |
|||
| ? | 6162-73-3512 | • HOUSING | 1 | SN: 18607- |
|||
| ? | 6162-73-3380 | • BUSHING | 1 | SN: 18607- |
|||
| ? | 6162-33-6140 | • BUSHING | 1 | SN: 18607- |
|||
| ? | 6162-73-3530 | COVER | 1 | SN: 18607- |
|||
| ? | 6162-73-3541 | GASKET | 1 | SN: 18607- |
|||
| ? | 01010-81030 | BOLT | 4 | SN: 18607- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 18607- |
|||
| ? | 6162-73-3271 | SEAL,OIL | 1 | SN: 20165- |
|||
| ? | □6162-73-3270 | SEAL,OIL | 1 | SN: 18607-20164 |
|||
| ? | 6162-73-3211 | GEAR,INJECTION | 1 | SN: 18607- |
|||
| ? | 6162-73-3621 | SHAFT | 1 | SN: 18607- |
|||
| ? | 04010-00516 | KEY | 1 | SN: 18607- |
|||
| ? | 6162-33-6160 | METAL | 2 | SN: 18607- |
|||
| ? | 6162-73-3150 | NUT | 1 | SN: 18607- |
|||
| ? | 6162-73-3160 | WASHER | 1 | SN: 18607- |
|||
| ? | 07043-00108 | PLUG | 2 | SN: 18607- |
|||
| ? | 07000-63115 | O-RING | 1 | SN: 18607- |
|||
| ? | 07000-62016 | O-RING | 1 | SN: 18607- |
|||
| ? | 01010-81235 | BOLT | 5 | SN: 18607- |
|||
| ? | 01602-01236 | WASHER,SPRING | 5 | SN: 18607- |
|||
| ? | 04010-01032 | KEY | 1 | SN: 18607- |
|||
| ? | 6162-73-3660 | WASHER | 2 | SN: 18607- |
|||
| ? | 01583-02012 | NUT | 2 | SN: 18607- |
|||
| ? | 07043-50108 | PLUG | 1 | SN: 18607- |
