| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-23-7611 | BRACKET | 1 | SN: 19259-@ |
|||
| ? | 6162-23-7610 | BRACKET | 1 | SN: 18607-19258 |
|||
| ? | 01010-81240 | BOLT | 3 | SN: 18607-@ |
|||
| ? | 01010-81245 | BOLT | 1 | SN: 18607-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 4 | SN: 18607-@ |
|||
| ? | 01640-01223 | WASHER | 4 | SN: 18607-@ |
|||
| ? | 04020-00820 | PIN,DOWEL | 2 | SN: 18607-@ |
|||
| ? | 6162-73-5210 | PIPE,INJECTION¤ NO.1 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5220 | PIPE,INJECTION¤ NO.2 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5230 | PIPE,INJECTION¤ NO.3 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5240 | PIPE,INJECTION¤ NO.4 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5250 | PIPE,INJECTION¤ NO.5 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5260 | PIPE,INJECTION¤ NO.6 | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5910 | RUBBER | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5920 | CLAMP | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5930 | CLAMP | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5920 | CLAMP | 1 | SN: 18607-@ |
|||
| ? | 01010-80835 | BOLT | 2 | SN: 18607-@ |
|||
| ? | 01010-80845 | BOLT | 2 | SN: 18607-@ |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 18607-@ |
|||
| ? | 6162-73-5940 | SPACER | 2 | SN: 18607-@ |
|||
| ? | 6162-73-5510 | CLAMP¤ WITH THREAD | 8 | SN: 18607-@ |
|||
| ? | 6162-73-5520 | CLAMP | 10 | SN: 18607-@ |
|||
| ? | 6162-73-5670 | BRACKET | 1 | SN: 18607-@ |
|||
| ? | 01010-80630 | BOLT | 8 | SN: 18607-@ |
|||
| ? | 01010-80635 | BOLT | 1 | SN: 18607-@ |
|||
| ? | 01010-80820 | BOLT | 2 | SN: 18607-@ |
|||
| ? | 01602-00619 | WASHER,SPRING | 9 | SN: 18607-@ |
|||
| ? | 01602-00825 | WASHER,SPRING | 2 | SN: 18607-@ |
|||
| ? | 6164-71-4910 | COVER | 6 | SN: 18607-@ |
|||
| ? | 6162-74-5810 | TUBE,OIL SUPPLY | 1 | SN: 18607-@ |
|||
| ? | 6162-53-8620 | CLIP | 1 | SN: 18607-@ |
|||
| ? | 6162-73-5860 | PIPE,OIL SPILL | 1 | SN: 18607-@ |
|||
| ? | 07206-30710 | BOLT,JOINT | 1 | SN: 18607-@ |
|||
| ? | 07005-01412 | GASKET | 3 | SN: 18607-@ |
|||
| ? | 07005-01012 | GASKET | 2 | SN: 18607-@ |
|||
| ? | 6127-71-5710 | BOLT,JOINT | 1 | SN: 18607-@ |
|||
| ? | 6162-74-5820 | TUBE,OIL SPILL | 1 | SN: 18607-20472 |
|||
| ? | 07005-01612 | GASKET | 2 | SN: 18607-@ |
