| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-74-1310) | INJECTION PUMP ASS'Y | 1 | SN: 18607-20472 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B6G5 TO A4010-G6G5. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105664-0200 | • COUPLING ASS'Y | 1 | SN: 18607-20472 |
|||
| ? | DK156636-1500 | • • COUPLING | 1 | SN: 18607-20472 |
|||
| ? | DK156633-6800 | • • BOLT | 2 | SN: 18607-20472 |
|||
| ? | DK156622-3100 | • • BUSHING | 2 | SN: 18607-20472 |
|||
| ? | DK156605-4800 | • • PLATE | 8 | SN: 18607-20472 |
|||
| ? | DK156615-4100 | • • WASHER | 2 | SN: 18607-20472 |
|||
| ? | DK156613-1500 | • • PLATE | 1 | SN: 18607-20472 |
|||
| ? | DK156615-4200 | • • WASHER | 2 | SN: 18607-20472 |
|||
| ? | DK014111-4440 | • • WASHER,SPRING | 2 | SN: 18607-20472 |
|||
| ? | DK013121-4040 | • • NUT | 2 | SN: 18607-20472 |
|||
| ? | DK156633-6900 | • • BOLT | 2 | SN: 18607-20472 |
|||
| ? | DK156622-3200 | • • BUSHING | 2 | SN: 18607-20472 |
|||
| ? | DK156615-4100 | • • WASHER | 2 | SN: 18607-20472 |
|||
| ? | DK014111-4440 | • • WASHER,SPRING | 2 | SN: 18607-20472 |
|||
| ? | DK013121-4040 | • • NUT | 2 | SN: 18607-20472 |
|||
| ? | DK156633-6900 | • • BOLT | 2 | SN: 18607-20472 |
|||
| ? | DK156622-3200 | • • BUSHING | 2 | SN: 18607-20472 |
|||
| ? | DK156615-4100 | • • WASHER | 2 | SN: 18607-20472 |
|||
| ? | DK156615-4300 | • • WASHER | 4 | SN: 18607-20472 |
|||
| ? | DK156609-6700 | • • COUPLING,CROSS | 1 | SN: 18607-20472 |
|||
| ? | DK014111-4440 | • • WASHER,SPRING | 2 | SN: 18607-20472 |
|||
| ? | DK013121-4040 | • • NUT | 2 | SN: 18607-20472 |
|||
| ? | DK156633-7000 | • • BOLT | 2 | SN: 18607-20472 |
|||
| ? | DK156622-3300 | • • BUSHING | 2 | SN: 18607-20472 |
|||
| ? | DK156605-4800 | • • PLATE | 8 | SN: 18607-20472 |
|||
| ? | DK156615-4100 | • • WASHER | 2 | SN: 18607-20472 |
|||
| ? | DK014111-4440 | • • WASHER,SPRING | 2 | SN: 18607-20472 |
|||
| ? | DK013121-4040 | • • NUT | 2 | SN: 18607-20472 |
|||
| ? | DK156633-7100 | • • BOLT | 4 | SN: 18607-20472 |
|||
| ? | DK029200-8050 | • • NUT | 4 | SN: 18607-20472 |
