| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-74-1310) | INJECTION PUMP ASS'Y | 1 | SN: 18607-20472 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B6G5 TO A4010-G6G5. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105955-0110 | • GOVERNOR ASS'Y | 1 | SN: 18607-20472 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D6G5 AND A4010-E6G5. | ||||||
| ? | DK159570-0200 | • • HOUSING | 1 | SN: 18607-20472 |
|||
| ? | DK020118-2840 | • • BOLT | 6 | SN: 18607-20472 |
|||
| ? | DK029622-5190 | • • SEAL,OIL | 1 | SN: 18607-20472 |
|||
| ? | DK159574-0100 | • • SPRING | 1 | SN: 18607-20472 |
|||
| ? | DK153400-0200 | • • SEAT,SPRING | 1 | SN: 18607-20472 |
|||
| ? | DK159574-0200 | • • CONNECTOR | 1 | SN: 18607-20472 |
|||
| ? | DK020106-2040 | • • BOLT | 1 | SN: 18607-20472 |
|||
| ? | DK159564-0501 | • • PLATE | 1 | SN: 18607-20472 |
|||
| ? | DK020105-0840 | • • BOLT | 1 | SN: 19338-20472 |
|||
| ? | DK159574-1200 | • • GASKET | 1 | SN: 19338-20472 |
|||
| ? | DK155404-1400 | • • CAP | 1 | SN: 19338-20472 |
|||
| ? | DK159574-0500 | • • PLATE | 1 | SN: 19338-20472 |
|||
| ? | DK154007-0500 | • • ADAPTER | 1 | SN: 19338-20472 |
|||
| ? | DK010038-1840 | • • BOLT | 1 | SN: 19338-20472 |
|||
| ? | DK014110-8440 | • • WASHER,SPRING | 1 | SN: 19338-20472 |
|||
| ? | DK159574-1100 | • • GEAR | 1 | SN: 19338-20472 |
|||
| ? | DK014111-8420 | • • WASHER,SPRING | 1 | SN: 19338-20472 |
|||
| ? | DK013131-8120 | • • NUT | 1 | SN: 19338-20472 |
|||
| ? | DK025805-1910 | • • KEY,WOODRUFF | 1 | SN: 19338-20472 |
|||
| ? | DK479748-2020 | • • SENSOR | 1 | SN: 19338-20472 |
