| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-23-3020 | COVER ASS'Y | 1 | SN: 18607-19337 |
|||
| ? | ☆ | • COVER,FRONT | 1 | SN: 18607-19337 |
|||
| ? | 07043-50108 | • PLUG | 1 | SN: 18607-19337 |
|||
| ? | 07046-11216 | • PLUG | 4 | SN: 18607-19337 |
|||
| ? | 07046-11816 | • PLUG | 3 | SN: 18607-19337 |
|||
| ? | 6162-23-3251 | GASKET | 1 | SN: 18607-19337 |
|||
| ? | 01011-31410 | BOLT | 6 | SN: 18607-19337 |
|||
| ? | 01602-01442 | WASHER,SPRING | 6 | SN: 18607-19337 |
|||
| ? | 01010-81285 | BOLT | 2 | SN: 18607-19337 |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 18607-19337 |
|||
| ? | 6162-23-3370 | PLATE | 1 | SN: 18607-19337 |
|||
| ? | 01010-31430 | BOLT | 1 | SN: 18607-19337 |
|||
| ? | 01602-01442 | WASHER,SPRING | 1 | SN: 18607-19337 |
|||
| ? | 6162-23-3380 | POINTER | 1 | SN: 18607-19337 |
|||
| ? | 01010-80820 | BOLT | 3 | SN: 18607-19337 |
|||
| ? | 01010-80825 | BOLT | 2 | SN: 18607-19337 |
|||
| ? | 01602-00825 | WASHER,SPRING | 5 | SN: 18607-19337 |
|||
| ? | 01640-20816 | WASHER | 2 | SN: 18607-19337 |
|||
| ? | 6162-23-3390 | COVER | 1 | SN: 18607-19337 |
|||
| ? | 6162-23-3291 | GASKET | 1 | SN: 18607-19337 |
|||
| ? | 07000-01009 | O-RING | 1 | SN: 18607-19337 |
|||
| ? | 01010-80825 | BOLT | 6 | SN: 18607-19337 |
|||
| ? | 01602-00825 | WASHER,SPRING | 6 | SN: 18607-19337 |
|||
| ? | 6162-23-3230 | COVER | 1 | SN: 18607-19337 |
|||
| ? | 01010-80816 | BOLT | 9 | SN: 18607-19337 |
|||
| ? | 01602-00825 | WASHER,SPRING | 9 | SN: 18607-19337 |
|||
| ? | 6162-23-9930 | TRUNNION | 1 | SN: 18607-19337 |
|||
| ? | 07000-65175 | O-RING | 1 | SN: 18607-19337 |
|||
| ? | 6162-23-3510 | SEAL¤ FRONT | 1 | SN: 18607-19337 |
|||
| ? | 6215-29-4320 | FRONT SEAL ASS'Y,(REPAIR PARTS) | 1 | SN: 18607-19337 |
|||
| ? | ☆ | • SEAL¤ FRONT | 1 | SN: 18607-19337 |
|||
| ? | ☆ | • SLEEVE | 1 | SN: 18607-19337 |
|||
| ? | 795-902-1410 | TOOL,(NOT SHOWN) | 1 | SN: 18607-19337 |
|||
| ? | 6162-23-3960 | PLATE | 1 | SN: 18607-19337 |
|||
| ? | 6162-23-3970 | GASKET | 1 | SN: 18607-19337 |
|||
| ? | 01010-80616 | BOLT | 2 | SN: 18607-19337 |
|||
| ? | 01602-00619 | WASHER,SPRING | 2 | SN: 18607-19337 |
|||
| ? | 6110-73-6231 | PLUG | 1 | SN: 18607-19337 |
|||
| ? | 07005-00812 | GASKET | 1 | SN: 18607-19337 |
|||
| ? | (09920-00150) | LIQUID GASKET,LG-7¤ 150G | A/R | SN: 18607-19337 |
