| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6503-20-1101 | TURBOCHARGER ASS'Y,(KTR150-13A) | 1 | SN: 19254-20361 |
|||
| ? | ♦6503-20-1100 | TURBOCHARGER ASS'Y,(KTR150-13A) | 1 | SN: 18607-19253 |
|||
| ? | 6503-20-1203 | • ROTOR ASS'Y | 1 | SN: 18607-20361 |
|||
| ? | (★6503-20-2211) | • • IMPELLER,BLOWER | 1 | SN: 18607-20361 |
|||
| ? | (★6503-20-1222) | • • ROTOR,TURBINE | 1 | SN: 18607-20361 |
|||
| ? | (★6503-20-1310) | • • COLLAR,THRUST | 1 | SN: 18607-20361 |
|||
| ? | (★6503-20-1330) | • • FLINGER | 1 | SN: 18607-20361 |
|||
| ? | (★6502-12-1352) | • • NUT | 1 | SN: 18607-20361 |
|||
| ? | 6502-12-1341 | • RING,SEAL | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1340 | • RING,SEAL | 2 | SN: 18607-20361 |
|||
| ? | 6503-20-1411 | • HOUSING,BLOWER | 1 | SN: 19254-20361 |
|||
| ? | 6503-20-1410 | • HOUSING,BLOWER | 1 | SN: 18607-19253 |
|||
| ? | 6503-20-2422 | • PLATE,BACK | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-9561 | • HOUSING,TURBINE | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1520 | • SHIELD,HEAT | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1530 | • LOCK | 6 | SN: 18607-20361 |
|||
| ? | 6503-20-1540 | • LOCK | 6 | SN: 18607-20361 |
|||
| ? | 01020-01020 | • BOLT | 12 | SN: 18607-20361 |
|||
| ? | 6503-20-2660 | • HOUSING,CENTER | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1620 | • BEARING,JOURNAL | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1630 | • BEARING,THRUST | 1 | SN: 18607-20361 |
|||
| ? | 01650-21012 | • WASHER,LOCK | 4 | SN: 18607-20361 |
|||
| ? | 01010-E1020 | • BOLT | 4 | SN: 18607-20361 |
|||
| ? | 07000-E2095 | • O-RING | 1 | SN: 18607-20361 |
|||
| ? | 04025-00412 | • PIN,SPRING | 1 | SN: 18607-20361 |
|||
| ? | 6503-20-1720 | • V-BAND | 1 | SN: 18607-20361 |
|||
| ? | 6505-99-9011 | • PLATE¤ NAME | 1 | SN: 19254-20361 |
|||
| ? | 6503-20-1910 | • PLATE¤ NAME | 1 | SN: 18607-19253 |
|||
| ? | 04418-02550 | • SCREW | 2 | SN: 18607-20361 |
