| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6503-20-1101) | TURBOCHARGER ASS'Y,(SEE FIG.A1530-B6D2) | 1 | SN: 19254-20361 |
|||
| ? | (♦6503-20-1100) | TURBOCHARGER ASS'Y,(SEE FIG.A1530-B6D2) | 1 | SN: 18607-19253 |
|||
| ? | 6162-83-2810 | GASKET | 1 | SN: 18607-20361 |
|||
| ? | 6685-11-5550 | NUT | 4 | SN: 18607-20361 |
|||
| ? | 6164-11-4450 | BOLT | 4 | SN: 18607-20361 |
|||
| ? | 6162-53-8410 | HOSE,SUPPLY | 1 | SN: 18607-20361 |
|||
| ? | 6151-53-8190 | CLIP | 2 | SN: 18607-20361 |
|||
| ? | 6204-81-6710 | SPACER | 1 | SN: 18885-20361 |
|||
| ? | 6204-81-6740 | SPACER | 1 | SN: 18607-18884 |
|||
| ? | 6141-64-2560 | SPACER | 1 | SN: 18607-20361 |
|||
| ? | 01010-80825 | BOLT | 1 | SN: 18607-20361 |
|||
| ? | 01010-80835 | BOLT | 1 | SN: 18885-20361 |
|||
| ? | 01010-80820 | BOLT | 1 | SN: 18607-18884 |
|||
| ? | 01602-00825 | WASHER,SPRING | 2 | SN: 18607-20361 |
|||
| ? | 01011-81000 | BOLT | 2 | SN: 18607-20361 |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 18607-20361 |
|||
| ? | 6162-53-8180 | BRACKET | 2 | SN: 18607-20361 |
|||
| ? | 6162-53-8170 | NIPPLE | 1 | SN: 18607-20361 |
|||
| ? | 6162-53-8250 | TUBE,SUPPLY | 1 | SN: 18607-20361 |
|||
| ? | 07214-50813 | CONNECTOR | 1 | SN: 18607-20361 |
|||
| ? | 6112-23-6971 | SPACER | 1 | SN: 18607-20361 |
|||
| ? | 04434-50810 | CLIP | 1 | SN: 18607-20361 |
|||
| ? | 01011-81020 | BOLT | 1 | SN: 18607-20361 |
|||
| ? | 01602-01030 | WASHER,SPRING | 1 | SN: 18607-20361 |
|||
| ? | 01642-01016 | WASHER | 1 | SN: 18607-20361 |
|||
| ? | 6128-51-8152 | GASKET | 2 | SN: 18607-20361 |
|||
| ? | 6125-51-8130 | ORIFICE | 1 | SN: 18607-20361 |
|||
| ? | 01010-80835 | BOLT | 2 | SN: 18607-20361 |
|||
| ? | 01602-00825 | WASHER,SPRING | 2 | SN: 18607-20361 |
|||
| ? | 6162-53-8350 | FLANGE | 1 | SN: 18607-20361 |
|||
| ? | 6162-53-8230 | PIPE,DRAIN | 1 | SN: 18607-20361 |
|||
| ? | 6127-51-6822 | GASKET | 2 | SN: 18607-20361 |
|||
| ? | 01010-81025 | BOLT | 4 | SN: 18607-20361 |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 18607-20361 |
|||
| ? | 6162-53-8240 | PIPE | 1 | SN: 18607-20361 |
|||
| ? | 6127-51-8470 | HOSE | 1 | SN: 18607-20361 |
|||
| ? | 07281-00489 | CLAMP | 2 | SN: 18607-20361 |
|||
| ? | 6162-23-6530 | PLATE | 1 | SN: 18607-20361 |
|||
| ? | 6127-51-6822 | GASKET | 1 | SN: 18607-20361 |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 18607-20361 |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 18607-20361 |
