| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1251 050 H92 | PANEL ASSEMBLY, INSTRUMENT | 1 | ||||
| ? | 1271 271 H1 | • PANEL, INSTRUMENT | 1 | ||||
| ? | 1271 270 H1 | • PROGRAPH, INSTRUMENT PANEL | 1 | ||||
| ? | 141 662 | • VOLTMETER | 1 | ||||
| ? | 37 702 A | • SWITCH, HORN | 1 | ||||
| ? | 149 020 | • GAUGE, HYDRAULIC OIL TEMPERATURE | 1 | ||||
| ? | 159 735 | • GAUGE, ENGINE WATER TEMPERATURE | 1 | ||||
| ? | 141 663 | • GAUGE, FUEL LEVEL | 1 | ||||
| ? | 282 437 R91 | • SWITCH, NEUTRAL TRAVEL | 1 | ||||
| ? | 141 661 | • GAUGE, ENGINE OIL PRESSURE | 1 | ||||
| ? | 27 022 | • CABLE - VOLTMETER TO GROUND SCREW | 1 | ||||
| ? | 160 021 | • HARNESS, GAUGE WIRING | 1 | ||||
| ? | 1431 451 H91 | • HARNESS, GAUGE GROUND WIRING | 1 | ||||
| ? | 51 045 H1 | • HARNESS, INSTRUMENT PANEL WIRING | 1 | ||||
| ? | 1433 458 H1 | GAUGE, TACHOMETER/HOURMETER - 66A, D66A, PD66A | 1 | ||||
| ? | 1432 650 H1 | GAUGE, TACHOMETER/HOURMETER - A66A | 1 | ||||
| ? | 82 837 | SCREW, MACHINE | 4 | ||||
| ? | 154 852 | WASHER, FLAT | 4 | ||||
| ? | 160 017 | MOUNT, SHOCK | 4 |
