Номер на схеме	Каталожный номер	Название	Количество
?	86 140	FITTING, GREASE	1
?	31 279 H45	BOLT	4
?	48 015	WASHER, LOCK	4
?	128 174	CAP, BEARING	1
?	83 835	BOLT	4
?	128 177	RETAINER	1
?	71 405	RACE, INNER	1
?	129 675	BEARING	1
?	128 179	SPACER	1
?	128 182	SEAL, GREASE	1
?	128 178	SHAFT, PIVOT	1
?	128 182	SEAL, GREASE	1
?	128 179	SPACER	1
?	161 441	BEARING ASSEMBLY	1
?	128 177	RETAINER	1
?	83 835	BOLT	4
?	128 173	CAP, BEARING	1
?	54 118	BOLT	6
?	61 148	FITTING, GREASE	1
?	142 899	SPINDLE	1
?	1432 469 H91	YOKE	1
?	1250 069 H91	FRAME	1
?		CYLINDER ASSEMBLY, STEERING (SEE PG 10-066)	-29	10-066
?	128 175	SEAL, RING	1
?	48 514	O-RING	1
?	101 175	CONE, BEARING	1
?	101 176	CUP, BEARING	1
?	128 858	CUP, BEARING	1
?	128 859	CONE, BEARING	1
?	128 184	SHIM - .005	A/R
?	128 185	SHIM - .007	A/R
?	128 186	SHIM - .020	A/R
?	128 181	RETAINER	1
?	107 403	BOLT	4
?	47 532	GASKET	1
?	128 176 H45	CAP, BEARING	1
?	70 106	BOLT	4
?	33 384 H45	WASHER, LOCK	4
?	61 150	FITTING, GREASE	1
