Номер на схеме	Каталожный номер	Название	Количество
?	416-46-A1200	FRAME, REAR	1	F1
?	417-875-1762	FRAME, REAR	1	F2
?	416-46-12160	BUSHING	1
?	07000-06150	O-RING	2
?	416-46-12133	SUPPORT, REAR AXLE	1
?	416-46-12160	BUSHING	1
?	07000-06150	O-RING	1
?	416-46-12152	PLATE, THRUST	1
?	01010-61250	BOLT	8
?	01643-31232	WASHER	8
?	416-46-12142	CAP, TRUNNION	1
?	416-46-12170	SHIM, 0.2mm	3
?	01010-61255	BOLT	8
?	01643-31232	WASHER	8
?	01011-32080	BLOT	4
?	01643-32060	WASHER	8
?	01580-02016	NUT	4
?	417-46-12201	COVER, L.H	1
?	421-09-12320	HOLDER	1
?	417-06-12280	PLATE	1
?	01220-40412	SCREW	5
?	01580-10403	NUT	5
?	01601-20410	WASHER, SPRING	5
?	01010-51225	BOLT	2
?	01643-31232	WASHER	2
?	417-46-12220	COVER, R.H	1	F1
?	417-875-1770	COVER, R.H	1	F2
?	01010-51225	BOLT	2
?	01643-31232	WASHER	2
?	416-46-13210	WEIGHT, COUNTER	1
?	01010-32085	BOLT	2
?	01010-32095	BOLT	2
?	01643-32060	WASHER	4
?	417-46-13213	PIN	1		a
?	417-46-A1230	PIN	1		b
?	416-46-12210	BAR, FRAME LOCK	1
?	416-46-12230	PIN	1		a
?	416-46-A1120	PIN	1		b
?	04050-18055	PIN, COTTER	1
?	416-46-12320	PIN	1		a
?	416-46-A1150	PIN	1		b
?	04025-01065	• PIN, SPRING	2
?	421-46-12740	PIN	1
?	07049-01215	PLUG	1
?
?		F1 - FOR MACHINES EQUIPPED WITH GROUND DRIVEN STEERING.
?
?
?		F2 - FOR MACHINES NOT EQUIPPED WITH GROUND DRIVEN STEERING.
?
