| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | DIVIDER VALVE (SEE PG 04-006) | -29 | 04-006 | ||||
| ? | 07002-11423 | O-RING | 2 | ||||
| ? | 416-875-1250 | ELBOW, DIVIDER VALVE END | 1 | ||||
| ? | 07086-00204 | HOSE, DIVIDER VALVE TO CHECK VALVE ASSEMBLY | 1 | ||||
| ? | 417-875-1611 | ELBOW, CHECK VALVE END | 1 | ||||
| ? | CHECK VALVE ASSEMBLY (SEE PG 04-008) | -29 | 04-008 | ||||
| ? | 07040-13016 | PLUG | 1 | ||||
| ? | 07002-13034 | O-RING, PLUG | 1 | ||||
| ? | 07000-13032 | O-RING, SPLIT FLANGE | 1 | ||||
| ? | 07371-31049 | FLANGE, SPLIT - DIVIDER VALVE END | 2 | ||||
| ? | 07372-01035 | BOLT, MOUNT SPLIT FLANGE | 4 | ||||
| ? | 01643-51032 | WASHER | 4 | ||||
| ? | 417-875-1810 | HOSE, DIVIDER VALVE TO CROSS TUBE | 1 | ||||
| ? | 23T-62-12160 | CLIP, HOSE | 1 | ||||
| ? | 417-875-1690 | SPACER | 1 | ||||
| ? | 01011-51005 | BOLT, MOUNT HOSE CLIP | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 417-875-1730 | TUBE, HYDRAULIC TANK TO CONTROL VALVE | 1 |
