| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 704-31-24110 | PUMP, GROUND DRIVEN STEERING | 1 | ||||
| ? | 704-37-02030 | • BRACKET, PUMP MOUNTING | 1 | F1 | |||
| ? | 704-38-24010 | • CASE, GEAR | 1 | F1 | |||
| ? | 704-37-02180 | • COVER | 1 | F1 | |||
| ? | 704-18-24410 | • GEAR, DRIVE | 1 | F1 | |||
| ? | 705-18-24511 | • GEAR, DRIVEN | 1 | F1 | |||
| ? | 704-37-02350 | • BEARING | 4 | ||||
| ? | 704-37-02610 | • PLATE, SIDE | 2 | ||||
| ? | 704-37-02470 | • RING, SEAL | 2 | ||||
| ? | 704-37-02440 | • RING, BACK-UP | 2 | ||||
| ? | 704-37-02450 | • SEAL, BACK-UP | 4 | ||||
| ? | 07000-12100 | • O-RING | 2 | ||||
| ? | 04020-01024 | • PIN, DOWEL | 4 | ||||
| ? | 705-17-04630 | • BOLT | 4 | ||||
| ? | 705-17-04980 | • WASHER, LOCK | 4 | ||||
| ? | 705-17-02830 | • SEAL, OIL | 1 | ||||
| ? | 04065-04018 | • RING, RETAINING | 1 | ||||
| ? | |||||||
| ? | F1 - PARTS ARE SUPPLIED SEPARATELY ONLY TO DESIGNATED | ||||||
| ? | DEALERS WHICH ARE EQUIPPED WITH A HYDRAULIC PUMP | ||||||
| ? | TESTER. |
