Номер на схеме	Каталожный номер	Название	Количество
?	416-43-17323	PEDAL, BRAKE - LH	1
?	416-43-17313	PEDAL, BRAKE - RH	1
?	07020-00675	FITTING, GREASE	2
?	419-43-17711	PAD	2
?	06120-02520	BEARING, NEEDLE	4
?	06122-02504	SEAL, BEARING	4
?	416-43-17330	PIN	1
?	01010-51220	BOLT	1
?	01643-31232	WASHER	1
?	417-06-11231	SWITCH, NEUTRAL	1
?	417-43-17420	PLATE	1
?	01220-40320	SCREW	2
?	01580-10302	NUT	2
?	01641-20305	WASHER	4
?	417-43-17440	SPRING	1
?	417-43-17430	BUSHING	2
?	01641-20608	WASHER	1
?	04050-11612	PIN, COTTER	1
?	417-43-17450	PLATE	1
?	01010-50816	BOLT	2
?	01643-30823	WASHER	2
?	419-06-11324	SWITCH, STOP LAMP	1
?	416-43-17433	SUPPORT	1
?	01220-40425	SCREW	2
?	01641-20405	WASHER	4
?	01580-10403	NUT	2
?	01010-50816	BOLT	2
?	01643-30823	WASHER	2
?	113-43-11180	SPRING	2
?	04245-41438	ROD	1
?	04211-21478	YOKE	2
?	01582-11411	NUT	2
?	04205-11440	PIN	2
?	01641-21423	WASHER	2
?	04050-14022	PIN, COTTER	2
?	416-43-17341	LEVER	1
?	07020-00675	FITTING, GREASE	1
?	06120-02016	BEARING, NEEDLE	2
?	06122-02004	SEAL, BEARING	2
?	416-43-17350	PIN	1		a
?	416-43-A1110	PIN	1		b
?	01010-51220	BOLT	1
?	01643-31232	WASHER	1
?		MASTER BRAKE CYLINDER (SEE PG 03-048)	-29	03-048
?	01010-51040	BOLT, MOUNT MASTER BRAKE CYLINDER	4
?	01580-11008	NUT	4
?	01643-31032	WASHER	8
?	416-43-17361	ROD	1
?	04211-21478	YOKE	1
?	01582-11411	NUT	1
?	04205-11440	PIN	1
?	01641-21423	WASHER	1
?	04050-14022	PIN, COTTER	1
