Номер на схеме	Каталожный номер	Название	Количество
?	1268 855 H91	MOTOR ASSEMBLY, CRANKING	1
?	1460 009 H1	• SOLENOID	1
?	(NSS)	• BOLT, MOUNTING - M6x20	2
?	1460 010 H1	• DRIVE, CLUTCH	1
?	1460 011 H1	• HOLDER, BRUSH	1
?	(NSS)	• BOLT, MOUNTING - M5x15	2
?	(NSS)	• WASHER, FLAT - M5	2
?	1460 012 H1	• BRUSH, GROUND	2
?	(NSS)	• BOLT, MOUNTING - M4x5	2
?	1460 013 H1	• BRUSH, INSULATED	2
?	(NSS)	• BOLT, MOUNTING - M4x5	2
?	1460 028 H1	• BUSHING, HOUSING	1
?	1460 014 H1	• SPRING, BRUSH	4
?	1460 015 H1	• BEARING, DE ARMATURE	1
?	1460 016 H1	• BEARING, CE ARMATURE	1
?	1460 017 H1	• BEARING, CENTER SUPPORT	1
?	1460 018 H1	• LEVER, SHIFT	1
?	(NSS)	• BOLT, MOUNTING - M6x50	1
?	(NSS)	• WASHER, FLAT - M6	1
?	(NSS)	• NUT, HEX - M6	1
?	1460 019 H1	• STOP ASSEMBLY, PINION	1
?	(NSS)	• • STOP, PINION	1
?	(NSS)	• • CLIP, RING	2
?	1460 021 H1	• HOUSING, COMMUTATOR END	1
?	(NSS)	• BOLT, MOUNTING - M6x181	2
?	1460 022 H1	• SHAFT, DRIVE	1
?	1460 023 H1	• BRACKET, ARMATURE SUPPORT	1
?	(NSS)	• BOLT, MOUNTING - M6x60	2
?	(NSS)	• BOLT, MOUNTING - M6x35	1
?	(NSS)	• PIN, DOWEL	1
?	1460 024 H1	• SUPPORT, DRIVE SHAFT	1
?	1460 025 H1	• HOUSING, DRIVE END	1
?	1460 026 H1	• FRAME AND FIELD	1
?	1460 027 H1	• O-RING, CE FRAME	1
?	1460 020 H1	• ARMATURE	1
?	(NSS)	• SEAL, SUPPORT BRACKET	1
?	(NSS)	• WASHER, FIBER	1
?	(NSS)	• WASHER, THIN	A/R
?	(NSS)	• WASHER, THICK	1
?	(NSS)	• O-RING, ACCESS PLUG	1
?	(NSS)	• O-RING	1
?	(NSS)	• PLUG, ACCESS	1
?
?		F1 - FOR MOUNTING HARDWARE SEE PG 01-007.
?
