| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 416-22-10010 | AXLE ASSEMBLY, FRONT | 1 | F1 | |||
| ? | 417-22-10004 | AXLE ASSEMBLY, FRONT | 1 | F2 | |||
| ? | • DIFFERENTIAL, FRONT (SEE PG 03-010) | -29 | 03-010 | ||||
| ? | 07044-13620 | • PLUG, DRAIN | 1 | ||||
| ? | 07002-03634 | • O-RING, DRAIN PLUG | 1 | ||||
| ? | 419-22-13140 | • PLUG | 2 | ||||
| ? | 07002-03034 | • O-RING | 2 | ||||
| ? | 419-33-11460 | • BLEEDER | 2 | ||||
| ? | 566-32-11620 | • CAP, BLEEDER | 2 | ||||
| ? | 417-22-13223 | • HOUSING, LH | 1 | F3 | |||
| ? | 417-22-23220 | • HOUSING, LH | 1 | F4 | |||
| ? | 417-22-13213 | • HOUSING, RH | 1 | F3 | |||
| ? | 417-22-23210 | • HOUSING, RH | 1 | F4 | |||
| ? | 419-22-13140 | • PLUG, CHECK OIL LEVEL | 2 | F3 | |||
| ? | 419-22-13140 | • PLUG, OIL FILL | 1 | F3 | |||
| ? | 417-22-23250 | • DIPSTICK, PLUG TYPE (OIL LEVEL) | 1 | F4 | |||
| ? | 07002-03034 | • O-RING, OIL LEVEL AND FILL PLUG | 3 | F3 | |||
| ? | 07002-03034 | • O-RING, DIPSTICK | 1 | F4 | |||
| ? | 417-22-13311 | • ADAPTER, BREATHER | 1 | ||||
| ? | 07030-01030 | • BREATHER | 1 | ||||
| ? | 01011-61625 | • BOLT, HOUSINGS TO DIFFERENTIAL | 28 | ||||
| ? | 01643-31645 | • WASHER | 28 | ||||
| ? | 22X-22-13171 | • PLATE, NAME (LIMITED SUPPLY) | 1 | ||||
| ? | 04418-03060 | • SCREW | 4 | ||||
| ? | |||||||
| ? | F1 - AXLE EQUIPPED WITH FILL PLUG - S/N NOT AVAILABLE. | ||||||
| ? | |||||||
| ? | F2 - AXLE EQUIPPED WITH PLUG TYPE DIPSTICK - S/N NOT AVAILABLE. | ||||||
| ? | |||||||
| ? | F3 - USED ON AXLES EQUIPPED WITH FILL PLUG ONLY. | ||||||
| ? | |||||||
| ? | F4 - USED ON AXLES EQUIPPED WITH PLUG TYPE DIPSTICK ONLY. | ||||||
| ? |
