| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-20-13012 | SHAFT ASSEMBLY, FRONT DRIVE | 1 | ||||
| ? | 417-20-13114 | • DRIVE SHAFT SUB ASSEMBLY | 1 | ||||
| ? | 417-20-13651 | • • YOKE AND SHAFT ASSEMBLY | 1 | ||||
| ? | (NSS) | • • • YOKE | 1 | ||||
| ? | (NSS) | • • • SHAFT | 1 | ||||
| ? | 417-20-12740 | • • • SEAL, OIL | 1 | ||||
| ? | 417-20-12680 | • • • COVER | 1 | ||||
| ? | 417-20-12640 | • • • FITTING, GREASE | 1 | ||||
| ? | 417-20-12620 | • • SPIDER ASSEMBLY | 1 | ||||
| ? | 417-20-12640 | • • FITTING, GREASE | 1 | ||||
| ? | 417-20-12690 | • • RING, SNAP | 2 | ||||
| ? | 416-20-13530 | • DEFLECTOR | 1 | ||||
| ? | 416-20-15112 | BEARING, FLANGE | 1 | ||||
| ? | 416-20-15660 | • FITTING, GREASE | 1 | ||||
| ? | 416-20-15620 | • SEAL | 2 | ||||
| ? | 416-20-15630 | • COVER | 2 | ||||
| ? | 01252-40520 | • BOLT | 12 | ||||
| ? | 01601-20513 | • WASHER, SPRING | 12 | ||||
| ? | 01010-31455 | BOLT | 4 | ||||
| ? | 01643-31445 | WASHER | 8 | ||||
| ? | 01580-01411 | NUT | 4 | ||||
| ? | 417-20-13030 | COUPLING ASSEMBLY | 1 | ||||
| ? | (NSS) | • COUPLING | 1 | ||||
| ? | 416-20-13530 | • DEFLECTOR | 1 | ||||
| ? | 416-20-13520 | HOLDER | 1 | ||||
| ? | 01011-61610 | BOLT | 1 | ||||
| ? | 01050-61045 | BOLT | 4 |
