| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 416-06-16213 | WIRE ASSEMBLY | 1 | ||||
| ? | 283-06-16190 | • FUSE 10A | 7 | ||||
| ? | 22W-06-13160 | • FUSE 20A | 5 | ||||
| ? | 415-06-12230 | • COVER FUSE | 1 | ||||
| ? | 416-06-16120 | PLATE | 1 | ||||
| ? | 01220-40620 | SCREW | 2 | ||||
| ? | 01641-20608 | WASHER | 2 | ||||
| ? | 416-06-16220 | WIRE ASSEMBLY | 1 | ||||
| ? | 416-06-A1200 | BOX | 1 | ||||
| ? | 416-06-16130 | SEAL | 2 | ||||
| ? | 421-06-16141 | SWITCH, FRONT WIPER | 1 | ||||
| ? | 417-927-AH00 | SWITCH, REAR WIPER | 1 | ||||
| ? | 416-06-A1210 | CAP (WITHOUT REAR WIPER) | 1 | ||||
| ? | 09415-00706 | CAP | 4 | ||||
| ? | 417-54-13510 | GROMMET | 1 | ||||
| ? | 08036-01414 | CLIP | 2 | ||||
| ? | 08034-00519 | STRAP, TIE | 1 | ||||
| ? | 08017-31903 | CONDUIT | 1 | ||||
| ? | 416-06-16350 | CONDUIT | 1 | ||||
| ? | 08017-31902 | CONDUCT | 2 | ||||
| ? | 08037-02512 | GROMMET | 1 | ||||
| ? | 416-06-16361 | COVER | 1 | ||||
| ? | 01010-30880 | BOLT | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | RELAY, BATTERY (SEE PG 01-062) | -29 | 01-062 |
