| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1269 029 H1 | BATTERY | 2 | ||||
| ? | 476 074 C1 | NUT, 3/8NC | 4 | ||||
| ? | 08000-00000 | TERMINAL (+) | 2 | ||||
| ? | 08000-00001 | TERMINAL (-) | 2 | ||||
| ? | 01010-30830 | • BOLT | 1 | ||||
| ? | 01580-00806 | • NUT | 1 | ||||
| ? | 01050-31018 | • BOLT | 1 | ||||
| ? | 01640-01016 | • WASHER | 1 | ||||
| ? | 416-06-A1110 | HOLDER | 1 | ||||
| ? | 417-06-11360 | ROD | 3 | ||||
| ? | 01580-10806 | NUT | 6 | ||||
| ? | 01643-30823 | WASHER | 3 | ||||
| ? | 416-06-A1190 | BOX, BATTERY | 1 | F1 | |||
| ? | 417-Z27-1110 | BOX, BATTERY | 1 | F2 | |||
| ? | 418-60-15150 | STOPPER, RUBBER | 1 | ||||
| ? | 01220-40630 | SCREW | 1 | ||||
| ? | 01641-20608 | WASHER | 1 | ||||
| ? | 424-09-12490 | HOLDER | 1 | ||||
| ? | 421-09-12320 | HOLDER | 1 | ||||
| ? | 01220-40410 | SCREW | 10 | ||||
| ? | 01641-20405 | WASHER | 10 | ||||
| ? | 01010-31240 | BOLT | 2 | ||||
| ? | 124-54-26540 | WASHER | 2 | ||||
| ? | 417-06-11340 | BRACKET | 1 | ||||
| ? | 08036-40814 | CLIP | 1 | ||||
| ? | 01010-31020 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 416-06-11320 | WIRE | 1 | ||||
| ? | 417-06-12111 | WIRE | 1 | ||||
| ? | 08038-06031 | CAP | 2 | ||||
| ? | 08038-06031 | CAP | 1 | ||||
| ? | 417-06-11321 | PLATE | 2 | F1 | |||
| ? | 416-Z27-1120 | PLATE | 2 | F2 | |||
| ? | 416-06-11330 | SPACER | 2 | ||||
| ? | 01601-20410 | WASHER | 4 | ||||
| ? | 01580-10403 | NUT | 4 | ||||
| ? | 416-06-11150 | GROMMET | 1 | ||||
| ? | |||||||
| ? | F1 - ON MACHINES NOT EQUIPPED WITH BACK-UP LIGHTS. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - ON MACHINES EQUIPPED WITH BACK-UP LIGHTS. | ||||||
| ? |
