| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 416-04-10211 | TANK, FUEL | 1 | ||||
| ? | 423-04-11362 | CAP (WITH LOCK) | 1 | ||||
| ? | 417-04-21230 | • GASKET | 1 | ||||
| ? | 07056-18416 | STRAINER, FUEL | 1 | ||||
| ? | 416-04-10150 | COVER | 1 | ||||
| ? | 421-04-11191 | GASKET | 1 | ||||
| ? | 01010-51020 | BOLT | 6 | ||||
| ? | 01643-31032 | WASHER | 6 | ||||
| ? | 416-04-10120 | SENSOR, FUEL LEVEL | 1 | ||||
| ? | 419-04-10140 | GASKET | 1 | ||||
| ? | 01220-40512 | SCREW | 5 | ||||
| ? | 01601-20513 | WASHER, SPRING | 5 | ||||
| ? | 416-04-10130 | VALVE, FUEL DRAIN | 1 | ||||
| ? | 416-04-10140 | COVER | 1 | ||||
| ? | 01010-30820 | BOLT | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | 01010-31235 | BOLT | 4 | ||||
| ? | 175-54-34170 | WASHER | 4 | ||||
| ? | 07214-71013 | CONNECTOR | 1 | ||||
| ? | 416-04-10160 | TUBE, VENT | 1 | ||||
| ? | 424-04-11120 | CLIP | 1 | ||||
| ? | 01010-31016 | BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 1237 610 H1 | ELBOW | 1 | ||||
| ? | 1128 007 C1 | HOSE, SUPPLY LINE (CUT BULK HOSE 3 | 1 | ||||
| ? | 1243 000 H1 | STRAINER, IN-LINE FUEL | 1 | ||||
| ? | 1128 007 C1 | HOSE, SUPPLY LINE (CUT BULK HOSE 34 | 1 | ||||
| ? | 279 025 R91 | CLAMP, HOSE | 4 | ||||
| ? | 742 917 C1 | HOSE, RETURN LINE (CUT BULK HOSE 34.5 | 1 | ||||
| ? | 1282 045 H1 | CLAMP, HOSE | 2 | ||||
| ? | 143 142 H1 | CLIP, RETURN LINE HOSE | 1 | ||||
| ? | 360 713 C1 | CLIP, SUPPLY LINE HOSE | 1 | ||||
| ? | 30 041 R1 | BOLT, CLIP MOUNTING | 1 | ||||
| ? | 30 177 R1 | WASHER | 1 |
