| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-43-11200 | PEDAL ASSEMBLY, ACCELERATOR | 1 | F1 | |||
| ? | 417-43-11210 | • PEDAL AND BODY | 1 | ||||
| ? | 417-43-11360 | • BOOT | 1 | ||||
| ? | 417-43-11310 | • ROD | 1 | ||||
| ? | 417-43-11320 | • PIN | 1 | ||||
| ? | 417-43-11330 | • CLIP | 2 | ||||
| ? | 417-43-11220 | • PLATE | 1 | ||||
| ? | 417-43-11240 | • SPRING | 1 | ||||
| ? | 417-43-11230 | • LEVER | 1 | ||||
| ? | 417-43-11250 | • BEARING | 2 | ||||
| ? | 417-43-11260 | • CLIP | 1 | ||||
| ? | 417-43-11290 | • SUPPORT | 1 | ||||
| ? | 417-43-11270 | • U-BOLT | 1 | ||||
| ? | 417-43-11280 | • NUT | 2 | ||||
| ? | 417-43-11340 | • SUPPORT | 1 | ||||
| ? | 01010-50616 | • BOLT | 2 | ||||
| ? | 417-43-11350 | • NUT | 2 | ||||
| ? | 01643-30623 | • WASHER | 1 | ||||
| ? | 01010-50860 | • BOLT | 1 | ||||
| ? | 01580-10806 | • NUT | 1 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE, SEE PG 01-031. | ||||||
| ? |
