| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-60-15610 | TANK, HYDRAULIC RESERVOIR | 1 | ||||
| ? | 421-60-11622 | GAUGE, SIGHT (RESERVOIR) | 1 | ||||
| ? | 07002-05234 | O-RING | 1 | ||||
| ? | 417-60-15420 | BREATHER ASSEMBLY (WITH LOCK) | 1 | ||||
| ? | 417-60-15430 | • CASE ASSEMBLY | 1 | ||||
| ? | 417-60-15330 | • PACKING | 1 | ||||
| ? | 417-60-15340 | • BOLT | 3 | ||||
| ? | 417-60-15460 | • BREATHER SUB ASSEMBLY | 1 | ||||
| ? | 417-60-15390 | • • COVER | 1 | ||||
| ? | 417-60-15380 | • • ELEMENT | 1 | ||||
| ? | 417-60-15370 | • • COVER | 1 | ||||
| ? | 417-60-15360 | • • VALVE ASSEMBLY | 1 | ||||
| ? | 417-60-15410 | • • BOLT | 1 | ||||
| ? | 417-60-15440 | • PLATE CAUTION | 1 | ||||
| ? | 417-60-15350 | • O-RING | 1 | ||||
| ? | 154-60-12170 | ELEMENT | 1 | ||||
| ? | 417-60-15130 | VALVE ASSEMBLY | 1 | ||||
| ? | 125-62-21170 | SPRING | 1 | ||||
| ? | 417-60-15120 | COVER | 1 | ||||
| ? | 424-60-15150 | PLUG | 1 | ||||
| ? | 07000-02010 | O-RING | 1 | ||||
| ? | 07000-12115 | O-RING | 1 | ||||
| ? | 01010-51230 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 421-60-11121 | COVER | 1 | ||||
| ? | 07000-05200 | O-RING | 1 | ||||
| ? | 01010-31025 | BOLT | 6 | ||||
| ? | 01643-31032 | WASHER | 6 | ||||
| ? | 07040-12414 | PLUG | 1 | ||||
| ? | 07002-12434 | O-RING | 1 | ||||
| ? | 07042-71019 | PLUG | 1 | ||||
| ? | 01010-31230 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 |
